Compaq V400
Compaq V400
Overview
Brand
Model
V400
Series
Type
Computer monitor
Screen size
14″
ECID
Tube
Pitch
0.28 mm
Visible area
13.2″ (diagonal)
Dimensions
H × W × D
335 mm × 370 mm × 394 mm
Weight
24.251 lb11 kg <br /> / 11 kg24.251 lb <br />
Power
Frequency
50Hz,60Hz
Consumption
75W (max)
Scan Range
Horizontal
31.5–48.4 kHz
Vertical
50–90 Hz
Inputs
Rear
Accessories
Parts
Documents
Contribute
The Compaq Presario V400 is a 14-inch (35.6 cm) colour CRT computer monitor with a 13.2-inch viewable image area, sold as part of Compaq's Presario line. Compaq's specification page lists a 0.28 mm dot pitch, a maximum resolution of 1024 × 768 non-interlaced, horizontal scanning from 31.5 to 48.4 kHz, vertical refresh from 50 to 90 Hz and 50 MHz of video bandwidth, with the signal carried over a 15-pin miniature D-sub connector.[1] The monitor is EPA Energy Star compliant and was produced in a 100–120 V 60 Hz version and a universal 100–240 V 50–60 Hz version, both rated under 75 W.[1]
References
- ↑ 1.0 1.1 Compaq, "V400 Features and Monitor Specifications", archived from ftp.compaq.com at https://ftp.zx.net.nz/pub/archive/ftp.compaq.com/pub/supportinformation/forum/Desktops/Monitors/V-series/V400/V400%20Specs_Motive.htm
